Screw oil press
  • Screw oil press
  • Screw oil press

Screw oil press

Description:
All kinds of models of screw automatic oil presses made by us are of many good advantages: material selection is exquisite, reasonable design, beauty shape, reliable quality, simple operation, less land occupation, labor saving, power saving, high yield, and oil quality is good, and so on.

    • plication:
      All kinds of models of screw automatic oil presses made by us are of many good advantages: material selection is exquisite, reasonable design, beauty shape, reliable quality, simple operation, less land occupation, labor saving, power saving, high yield, and oil quality is good, and so on. All technical indexes are leading in the same trade of the state-owned oil press. And the model of 6YZ-80 and 6YZ-100 are the new type products reformed by our factory engineers, which are the advanced equipment in the oilseeds processing machinery recently.

      Structure:
      There are many good advantages of this equipment: simple structure, easy to use, adaptable, high oil rate, energy-saving, and low noise. This series of machinery can be widely used to more than 20 kinds of easy and difficult plant oilseeds, such as peanuts, soybeans, rapeseed, cottonseed, sesame, olives, sunflowers, coconut, cocoa, seeds and so on. During pressing, it can be entirely squeezed one-time(except for some individual varieties).
      The process of pressing oil is filtered by vacuum, so the residue of the oil is rather little and ensures the hygiene degree of pure oil. Our company also produces the equipment of drum-express hydraulic oil, six to eight kilograms of raw materials only need six to ten minutes from raw materials into the machine to oil, which has been received good comments by customers. Additionally, we produce granule selected machines, automatic speculation seed machine, automatic oil filter, and electric control machines, etc. to equip with a variety of oil processing machines available for you to choose from.

      Oil material Oil press rate (%) Thickness of the material slag Residual oil ratio (%)
      Sesame 42-55 1.0-1.5 ≤7
      Peanut 40-50 0.8-2 ≤8
      Rapeseed 28-43 1.0-1.5 ≤8
      Sunflower seeds 30-45 1.2-1.5 ≤7
      Soy bean 10-16 0.8-1.5 ≤7

      Screw oil press advantages
      1. It has multiple functions, including vacuum filtration system, automatic heating device and control system
      2. Before pressing, some parts of the oil press such as the press chamber, press screw and press ring will be pre-heated.
      3. During pressing, the press can filter the oil in due time.
      4. The machine is matched with one controlling cabinet box for controlling all working of the machines.
      5. Labor saving and electricity saving, high oil yield and performance.
      6. Aesthetic appearance, highly structured, easy to installation.

    model Technical parameter 6YL-60 6YL-80 6YL-100 6YL-120 6YL-130 6YL-165
    Diameter of worm section 60mm 80mm 100mm 120mm 130mm 165mm
    Rotary speed of worm section 25-35rounds/min 40-50rounds/min 30-40rounds/min 30-40rounds/min 30-40rounds/min 30-40 rounds/min
    Diameter of inscribed circle of press boring 62mm 82mm 102mm 122 132 164mm




    Equipped force
    Main frame Y132M-6-1.5KW Y132M-6-5.5KW Y132M6-7.5KW Y132M-4-11 KW Y132M-4-18 KW Y132M-4-22 KW
    Vacuum pump Y80-4-0.55KW Y80-4-0.55KW Y801-4-1.5KW Y80-4-3KW Y80-4-3KW Y80-4-3KW
    heater 0.75 KW 2KW 2KW 3KW 3KW 3KW
    Capacity 10-30kg/h 50-80kg/h 80-150kg/h 100-200kg/h 200-400 kg/h 450-800kg/h
    Machine weight 80kg 500kg 700kg 1000kg 1300kg 180kg
    Overall dimension (L*W*H)mm 1000*538*1050 1500*1000*1800 1800*1000*1900 2000*1200*2000 2100*1200*2000 2200*1500*2100
